Studer 928 Service Manual

928 Mixing Console
Jumpers E 3/5
Edition:
07.02.01
3.1.2 INPUT UNIT STEREO 1.928.250
Insert
With the settings of jumpers J1...J4 the insert point can be placed either
before the equalizer or before the fader.
Jumper Insert Pre-EQ Insert Pre-Fader
J1 1-3 and 2-4 3-5 and 4-6
J2 1-3 and 2-4 3-5 and 4-6
J3 1-3 and 2-4 3-5 and 4-6
J4 1-3 and 2-4 3-5 and 4-6
Remote control
Each input unit is equipped with two remote control relays. One of
them produces the fader start signal for the LINE1 input, the other one
produces the fader start signal for the LINE2 input. The normally-open
contacts of these relays are terminated on the 9-pin D-type connector
of the rear panel.
The relay contacts can be used for remote control or signalization. The
function and the behavior of the remote control can be varied with jump-
ers J2, J3, J4, and J5 on the Side Board.
Remote control output
J5 Selection
Remote
output J2: 1-2 J2: 2-3
1-2 LINE1
REM Fader start pulse Fader start pulse
STOP Fader stop pulse Fader stop pulse
LINE2
REM = LOW for as long as the fader
is open and the ON key is
active.
Fader start pulse
STOP Fader start pulse Fader stop pulse
2-3 LINE1
REM Latching contact for as long as
the fader is open and the ON
key is active.
Latching contact for as long as
the fader is open and the ON
key is active.
STOP --- ---
LINE2
REM = LOW for as long as the fader
is open and the ON key is
active.
Latching contact for as long as
the fader is open and the ON
key is active.
STOP Latching contact for as long as
the fader is open and the ON
key is active.
---
