12
Bus Send Subpage
Each input channel can send signals to 4 mono busses (1-4), 4 stereo busses (5-8) and
master L/R.
① Channel Switch
Press the arrow-buttons, to choose previous or next channel within the same layer
② Bus-send enable
Press a bus button to send the active channel there, press again to disable the send.
③ PreFader/PostFader Switch
Switches between pre- and post-fader send to a bus. Pre-fader does not include the fader
gain value, which can be useful for effect sends or monitoring. Default is pre-fader.
④ PAN control
Controls the panning into a stereo bus. Default is 50|50 (middle). The PAN value can be
changed by dragging the slider or by turning the main encoder on the control panel. Double-
tap the numeric parameter control to reset the parameter to its default value.
⑤ Send level control
Controls the sent-level of the signal to the selected bus. This can be changed by moving
the on-screen slider up and down.
1
2
3
4
5
