13
Channel Output Subpage
Panning and level into master as well as Solo / Mute can be set here.
① Switch Channel
Press the arrow-buttons, to choose previous or next channel within the same layer
② PAN control
Controls the panning into master LR. Default is 50|50 (middle). The PAN value can be
changed through the on-screen encoder or by turning the main encoder on the control
panel. Double-tap the numeric parameter control to reset the parameter to its default value.
③ Solo
This is a copy of the hardware button on the front-panel. Press to enable or disable signal
sent to the solo monitor bus.
④ Mute
Like Solo, this is a copy of the hardware button on the front-panel. Press to mute or unmute
the channel, which will effectively mute or unmute all pre- and post-fader sends of the active
channel to all busses, including master L/R.
⑤ Fader control
This is a copy of the physical fader of the selected channel. You can change the on-screen
fader through touch and the physical fader will follow accordingly. Double-tap the numeric
parameter control to reset the parameter to its default value.
⑥ Level meter display
2
2
3 4
5 6
