STULZUltraSonic-SystemforDirectRoomHumidicationBNB-  Productdescription
4.6. Dimensional drawing
All dimensions in mm.
5
7
/
CAUTION
Precon gured lines.
Bearinmindthedimensionsofthepreconguredlinesforyourunitsize.
See "7.5. Electrical connection" on page 49.
Note
Key
Item Description Item Description
1 Ultrasonichumidier 10 Safetyoverow
2
Fan housing 11 Mist guide tube
3 Mist guide cover 12 Ring and nut
4
─
13
Installation foot
5
Metal connector
14
Airlter
6
Cable
15
Water supply *
7
Metal connector
16
Stop cock *
8
Cable
17
Air damper control
9
Water drain
18
Wallbracket(optional)
A:Unitwidth
P:Holespacingforthreadedjoint
* Provided by plant operator
