Stulz BNB Series - 7 Installation

© STULZ GmbH, Hamburg EN / 10-2015 / 1000683
-
33
-
STULZUltraSonic-SystemforDirectRoomHumidicationBNB-  Installation
7. Installation
Install the unit in such a way that the mist expelled by the fan is distributed uniformly everywhere in the
room. Please check that the product package is complete before installation.
CAUTION
Danger of death. Electric shock risk.
Faultywiringoftheswitchgearcabinetcancausethehumidiertobecomedefective.
The STULZ UltraSonicBNBultrasonichumidier may only be installed, connected and started up by
specialist electricians.
●
Switch gear cabinets must be wired as shown in the wiring diagrams provided.
WARNINGDANGER
CAUTION
Genuine parts.
Use only genuine STULZ parts and genuine spare parts for installation.
CAUTION
Horizontal position.
The unit must be mounted precisely horizontally.
●
Itisessentialtocheckthepositionofthehumidierbeforestartingitup!
NOTICE
CAUTION
Upright position.
Do not switch on the master switch under any circumstances if the unit is not in an upright position.
●
Itisessentialtocheckthepositionofthehumidierbeforestartingitup!
NOTICE
CAUTION
Adhere to set clearances.
Between the mist guide tube and any component that may be located in front of the unit, leave a clear-
ancethatisgreaterthanthehumidierdistance.
●
See section "5.1.Humidierdistance"onpage27.
NOTICE
CAUTION
Installation clearance.
Leaveminimumclearanceof500mmbetweentheupperedgeoftheultrasonichumidier
and the ceiling.
●
See section "7.2. Installation clearances" on page 36.
NOTICE
CAUTION
Minimum distance between units.
When several units are installed in a room, maintain a minimum distance of 300 mm between them.
●
See section "7.2. Installation clearances" on page 36.
NOTICE
