STULZUltraSonic-SystemforDirectRoomHumidicationBNB-  Installation
ULTRASONIC
or:
Pipe for demineralized
drinkingwater:
Ø 6 mm PE plastic tube
Connector
Inletjointinultrasonichumidier
ULTRASONIC
ULTRASONIC
Pipe for demineralized
drinkingwater:
Ø 6 mm stainless steel
Cutting ring
(inproductpackage)
Union nut
Inletjointinultrasonichumidier
Connection for demineral-
ized drinking water
Ø 6 mm PE plastic tube
Connector
Inletjointonultrasonichumidier
ULTRASONIC
ULTRASONIC
ULTRASONIC
ConnectiontoPEplastictube:
1
Cleanallcomponents(plastictube,
connector).
2
Screw the threaded end of the connec-
tor into the inlet joint on the ultrasonic
humidier.
4
Check that connections are secure.
3
Insert the plastic tube into the connector.
