Product description STULZ UltraSonic -System for duct humidication ENS 14 A - 18 A-
4.5. Technical data
The STULZ UltraSonic ENS ultrasonic humidier works on the principle of ultrasonic atomization. The
airow in the duct blows the mist, which was produced in a water tank with the aid of an transducer, into
the room to humidify it. The ultrasonic humidier consists of the atomization modules, the supply module
with solenoid valve that lets in the water supply, oat switches and a housing accommodating a fan. A
switch gear cabinet must be installed externally, which will house the open and closed-loop control sys-
tems and power supply for the unit.
Model (ENS) 14 A 18 A
Capacity* (kg/h) 14 18
Number of transducers 24 30
Operating voltage (V AC) 48 48
Rated power (W) 750 960
Empty weight (kg) 11 13
Dimensions HxWxD (mm) 190x785x150 190x950x150
Dimension P (mm)** 730 895
Flushing water volume (l)*** 3,4l 3,4l
Open-loop/closed loop control
Humidity measurement with set point/actual value
comparison
USM / USS 1303 USM / USS 1303
ON/OFF accessory set
1)
Set 4 Set 4
Proportional accessory set
1) 4)
Set 17 Set 17
ON/OFF control module with
"ON/OFF" time relay
2)
--- ---
* Capacity at a water level of 40 mm, air temperature of 26°C, water temperature of 26°C and voltage of 48 V.
Operating conditions: Ambient temperature 8°C to 40°C, relative humidity less than 90%.
Water supply: Only demineralized drinking water < 80 μS/cm may be supplied to the ultrasonic humidier.
The water pressure to the ultrasonic humidier must be between 0.5 bar and 6 bar, the water temperature
between 5°C and 40°C.
** See drawing "4.6. Dimensional drawing" on page 17.
*** When connected to a STULZ USM control cabinet and using factory settings.
1)
For installing in an on-site switch gear cabinet
2)
Up to humidier capacity of 3 kg/h
Selecting the required open-loop/closed-loop control system
Required control Type of control Possible components
3)
Humidity measurement with
actual value/setpoint comparison
Proportional control USM/USS controller
4)
External control with
control signal 0-10V DC / 0-1V DC
Proportional control USM/USS controller or
proportional control accessory set
1)
Please refer to our STULZ UltraSonic control manual for more information.
Visit our web site at www.stulz.com.
Here you can also download our manuals.
