Operation STULZ UltraSonic -System for duct humidication ENS 14 A - 18 A-
9.2.3. Dimensional drawing of booster fan
Item number Description
1 Humidier ENS 14 / 18 A
2 Droplet separator
3 Connector
4 Oscillator connection
5 Control system connection
6 Booster fan connection
7 T-piece*
8 Water supply
9 Safety overow
10 Water drainage threaded joint
11 Installation foot
12 Booster fan
13 Fan
14 Shut-off valve*
*Provided by plant operator
View "B"
View "A"
