This meter displays the odometer and two
trip meters when the ignition switch is in
the “ON” position.
If you press the trip knob when the ignition
switch is in the “LOCK” or “Acc” position,
the odometer/trip meter will light up. It is
possible to switch the indications while the
odometer/trip meter is lit up. If you do not
press the trip knob within 10 seconds of
illumination of the odometer/trip meter, the
odometer/trip meter will turn off.
The display can be switched as shown in
the following sequences by pressing the
trip knob.
Type A:
*: “ ” or “ ”, and “ ” or “ ” cannot
be displayed when the ignition switch is
in the “ON” position.
Type B:
*: “ ” or “ ” cannot be displayed when
the ignition switch is in the “ON” posi-
tion.
! Odometer
Type A
Type B
The odometer shows the total distance
that the vehicle has been driven.
! Double trip meter
Type A
Instruments and controls
3-9
– CONTINUED –
3
