4-2 Climate control
Ventilator control
& Center ventilators
Move the tab to adjust the flow direction.
& Side ventilators
1) Open
2) Close
3) Thumb-wheel
Move the tab to adjust the flow direction.
To open or close the ventilator, turn the
thumb-wheel up or down.
Climate control panel
Type A panel is used for the manual
climate control system.
Refer to “Manual climate control” F4-8.
Type B and C panels are used for the
automatic climate control systems.
Refer to “Automatic climate control system
(type B and C) ” F4-6 for automatic
operation.
Refer to “Manual climate control” F4-8 for
manual operation.
