3-26 Instruments and controls
CAUTION
To ensure safety, do not attempt to
set the time while driving, as an
accident from inadequate attention
to the road could result.
NOTE
If the battery is disconnected, the time
will be erased. After reconnecting the
battery, set the correct time.
Information display
1) Outside temperature indicator
2) Fuel consumption indicator
Withtheignitionswitchinthe“ON”
position, the outside temperature and fuel
consumption are indicated on the display.
For type A combination meter:
1) Information display switching knob
With the ignition switch in the “ON”
position, each press of the information
display switching knob toggles the display
in the following sequence.
For type B combination meter:
The fuel consumption indicator is linked
with the odometer/trip meter display on the
combination meter, according to the fol-
lowing chart.
