4-12 Climate control
mance if not properly maintained.
& Replacing an air filter
1. Remove the glove box.
(1) Open the glove box.
(2) Remove the damper shaft from the
glove box.
(3) While pushing the stoppers on
both sides of the glove box, swing
the glove box down and remove it.
2. Remove the air filter.
3. Replace the air filter element with a
new one.
CAUTION
The arrow mark on the filter must
point UP.
To Next Page
