Optional Installation Equipment
The following equipment also may be required, depending on your installation configuration:
• Insulated wire, 22-12 AWG, rated to 300 Volts for analog and alarm outputs
• Analog (4-20 mA) recorder
• Insulated wire (18-12 AWG, rated to 300 Volts) for AC power conduit
• An external circuit breaker or switch that disconnects both poles of the supply voltage, rated
appropriately, if using power conduit.
• PLC or SCADA system for use with Modbus
• 60 micron filter for sample inlet line
• USB printer (For a list of SUEZ recommended printers for the CheckPoint instruments, see our
website.)
Step 1: Install the Mounting Bracket (Optional)
If you will be installing the Sensor in a fixed (permanent) position, install the provided mounting
bracket in the desired location by fastening screws through the bracket slots. Refer to Figure 46:
Mounting Bracket Dimensions on page 106 for bracket dimensions. After the bracket has been
mounted, attach the Sensor to the bracket by placing the mounting posts in the wider portion of the
bracket cutouts and then pressing down firmly but gently.
NOTE: If you plan to install the Vial sampling kit during maintenance activities with the Sensor wall
mounted, allow at least 30.5 cm (12 in) on the right side of the Sensor for attaching the kit (see
Figure 44: Sensor Dimensions and Required Clearances, Front View with Vial Sampling Kit on
page 104).
Avoid direct sunlight and extreme temperatures; operating at elevated temperatures (greater than
40 °C) prevents proper operation, and operating at low temperatures (10 °C) can cause errors in
measurements. Also make sure there is at least 1.2 in of clearance between the wall and the back of
the Sensor.
If you will not be mounting the CheckPoint, attach the optional adhesive tubing clip to the back of the
Sensor, so you can restrain coiled sample cable while the Sensor is in transit.
