4. Make sure the analog output is enabled by highlighting Analog Output to toggle the analog
output state between On and Off.
5. Select Set Parameter (TOC, Conductivity/Resistivity, Temperature).
• Press F1 to select TOC, press F2 to select conductivity or resistivity, or press F3 to
select temperature as the analog output parameter. (You can specify whether data
should be reported as conductivity or resistivity via the Setup menu, Units of
Measure. Conductivity will be either temperature corrected or raw conductivity as
specified in the Setup menu.)
• The Analog Min screen displays, indicating the most recent minimum value for the
selected parameter. To change the value, use the Horizontal Scroll bar to select the
field, and use the Vertical Scroll bar to change the value in the selected field. Press
F1 to apply the new value.
• The Analog Max screen displays, indicating the most recent maximum value for the
selected parameter. To change the value, use the Horizontal Scroll bar to select the
field, and use the Vertical Scroll bar to change the value in the selected field. Press
F1 to apply the new value.
6. Analog MIN/MAX is also available without reselecting Set Parameter.
7. The Sensor allows you to set the output level when the Sensor switches into Standby mode,
when an error is detected, or when a warning is detected. Select Standby to set the Standby
output. Select Error to set the error output. Select Warning to set the Warning output.
• Use the Vertical Scroll bar to highlight a value, and then press the Enter key to select
that value.
• The available values are 0.0 mA, 2.5 mA, 4.0 mA, 20 mA, and Hold. The first four
options set the standby or error value to the specified value. The Hold option sets the
standby or error value to retain the last value output by the Sensor.
• Make sure you have set different values for Standby, Error, and Warning.
Binary Input
The CheckPoint can be configured with one remote start binary input, as follows:
The Binary Input screen shows the current state of the binary input.
1. Scroll to Binary Input and press .
2. Press F1 to toggle the binary input state between Enabled and Disabled. Set the value to
Enabled to enable remote start to begin the analysis.
