Parts
Cyclo® HBB Reducer
Table22.CycloReductionComponentParts(continued,refertoFig.8)
Model
Reduction Ratio Part Numbers
Overall Cyclo® Cyclo® Disc Eccentric Cam
B6120
B6125
21 6 AN9947G AP0037G
28 8 AN9948G AP0037G
39 11 AN9949G AP0038G
46 13 AN9950G AP0039G
53 15 AN9951G AP0038G
60 17 AN9952G AP0039G
74 21 AN9953G AP0040G
88 25 AN9954G AP0041G
102 29 AN1338G AP0041G
123 35 BQ396LG AP0042G
151 43 BQ397LG AP0043G
179 51 CN324LG AP0044G
207 59 BQ703LG AP0044G
249 71 CN325LG AP0045G
305 87 BS946LG AP0045G
C6140
C6145
21 6 AN9372G AN7775G-1
28 8 AN9373G AN7775G-1
39 11 AN9374G AN7775G-1
46 13 AN9375G AN7775G-2
53 15 AN9376G AN7775G-2
60 17 AN9377G AN7775G-2
74 21 AN9378G AN7775G-3
88 25 AN9379G AN7775G-3
102 29 AN9380G AN7775G-4
123 35 AN9381G AN7775G-4
151 43 AN9382G AN7775G-5
179 51 AN9383G AN7775G-5
207 59 AN9384G AN7775G-5
249 71 AN9385G AN7775G-6
305 87 AN9386G AN7775G-6
Model
Reduction Ratio Part Numbers
Overall Cyclo® Cyclo® Disc Eccentric Cam
D6160
D6165
21 6 AN9387G AN7776G-1
28 8 AN9388G AN7776G-1
39 11 AN9389G AN7776G-2
46 13 AN9390G AN7776G-2
53 15 AN9391G AN7776G-2
60 17 AN9392G AN7776G-3
74 21 AN9393G AN7776G-3
88 25 AN9394G AN7776G-3
102 29 AN9395G AN7777G-4
123 35 AN9396G AN7777G-4
151 43 AN9397G AN7777G-5
179 51 AN9398G AN7777G-5
207 59 AN9399G AN7777G-6
249 71 AN9400G AN7776G-7
305 87 AN9401G AN7777G-8
E6170
E6175
21 6 AN9402G AQ952LG-1
28 8 AN9403G AQ952LG-1
39 11 AN9404G AQ952LG-2
46 13 AN9405G AQ952LG-2
53 15 AN9406G AQ952LG-3
60 17 AN9407G AQ952LG-3
74 21 AN9408G AQ952LG-4
88 25 AN9409G AQ952LG-4
102 29 AN9410G AQ952LG-5
123 35 AN9411G AQ952LG-5
151 43 AN9412G AQ952LG-6
179 51 AN9413G AQ952LG-6
207 59 AN9414G AQ952LG-7
249 71 AN9415G AQ952LG-7
305 87 AN9416G AQ952LG-7
