Cyclo® HBB
6 Operation & Maintenance Manual
Cyclo® HBB
Storing and Transporting
Storage Location
• Storetheunitinaclean,dryarea.
• Do not store outdoors or in an area with high humidity, dust,
sudden temperature changes, or corrosive gases.
Storage Period
• Do not store the unit for longer than 6 months without
obtaining long-term storage procedures from Sumitomo.
• ConsultSumitomowhenstoringtheunitformorethan6
months. Rustproofing procedures are required.
• ConsultSumitomowhenexportingtheunit.Rustproong
procedures may be required.
Operation After Storage
Before operating the unit after an extended storage period,
ensure that non-metal parts, i.e., oil seals, o-rings, air breather,
have not deteriorated. Non-metal parts may deteriorate easily
from exposure to ambient conditions (i.e., extreme temperatures,
UV rays). Replace deteriorated parts with new ones before unit
start-up.
After starting the unit, verify that there is no abnormal noise,
vibration, and/or temperature rise. Immediately stop the unit and
call Sumitomo or your distributor if you observe any abnormality.
Transporting
• Do not stand directly under a unit suspended by a
lifting mechanism. Injury or death may occur if the
unit is dropped.
• Before lifting the unit, determine its weight (refer
tocatalog,packinglist,etc.)andensurethatthe
moving equipment will support the unit’s weight.
Never hoist or move a unit that exceeds the
moving equipment’s rated capacity or else
personnel injury and/or equipment damage may
occur.
• Do not allow the unit to drop or fall while moving.
Always use the eye bolts attached to the gear
housing (and on motor if supplied) when moving
the unit. After securing the unit to the machine,
removethemovinghooks/strapsfromtheeyebolts.
