4-4 Sun Fire V20z and Sun Fire V40z Servers—User Guide • March 2005
FIGURE 4-2
Locations of System Components in Sun Fire V40z Server, Top-Down View
Vertical
PCI slots (6)
Horizontal
PCI slot and
PCI riser
(under power
supply cage)
Hard disk drives (5)
in front-panel bays
DVD and
diskette drive
in front-panel bay
Optional
CPU card
(shown removed
from server)
Operator-panel
assembly in
front-panel bay
SCSI
backplane
Front
fan-cage
assembly
Rear
fan-cage
assembly
Power-supply
cage assembly
Memory VRM
(2 on mother-
board)
CPU VRM
(2 on mother-
board)
CPU VRM
(2 on optional
CPU card)
Memory VRM
(2 on optional
CPU card)
Memory
modules
(8 slots
on mother-
board)
Memory
modules
(8 slots
on option
a
CPU card
)
CPUs
(2 on
motherboard)
CPUs
(2 on optional
CPU card)
S
ystem
battery
(under power
supply cage)
(up to 2 power supplies)
