Chapter 1 Introduction to the Sun Fire™ V20z and Sun Fire V40z Servers
1-9
1.3.3 Sun Fire V40z Server Hardware System
Orientation
Before performing any service procedures, become familiar with the physical
orientation and features of your Sun Fire V40z server.
1.3.3.1 Sun Fire V40z Front and Back Panels
FIGURE 1-4
shows the front panel of the Sun Fire V40z server.
FIGURE 1-4
Front Panel of the Sun Fire V40z Server
Refer to “Operator Panel” on page 1-13 for more information about the operator
panel.
Platform power
button and LED
System
-
fault
LED
Locate button
and LED
Operator-panel
buttons (3)
Operator-panel
LCD display
Hard drive activity indicator LED
USB connector
