4 Mechanical Mounting User Manual
18
≥600mm
≥200mm
≥650mm
≥1000mm
≥500mm
In case of multiple inverters, reserve specific clearance between the
inverters.
≥600mm ≥600mm ≥600mm ≥200mm
In case of back-to-back installation, reserve
specific clearance between the two inverters.
Install the inverter at an appropriate height for ease of viewing LED
indicators and operating switches.
4.3 Installation Tools
Prepare the following tools before installation:
