SunStar Fortuna series User Manual

56
No. Function StepRange Initial value
[ Caution ]
If the specific items of the parameter are changed carelessly, they could break down or damage the machine, so the user must be
well-trained before using it.
Items No. 60~76: functions that check individual normal movement.
Items No. 77~79 : functions that check each analog input normal movement.
Item No. 80 : function that checks whether the synchronizer signal is working properly.
Item No. 81 : function that checks whether the encoder A/B is working properly.
Item No. 82 : function that checks whether the encoder R/S/T is working properly.
60 Checks the signal input INPUT00 (Button A)
61 Checks the signal input INPUT01 (Button B)
62 Checks the signal input INPUT02 (1/4 stitch Switch)
63 Checks the signal input INPUT03 (2/4 stitch Switch)
64 Checks the signal input INPUT04 (3/4 stitch Switch)
65 Checks the signal input INPUT05 (4/4 stitch Switch)
66 Checks the signal input INPUT06 (Left Switch)
67 Checks the signal input INPUT07 (Right Switch)
68 Checks the signal input INPUT10 (Manual presser foot-lift Switch)
69 Checks the signal input INPUT11 (Counter Switch)
70 Checks the signal input INPUT12 (PU 1/2 stitch Button)
71 Checks the signal input INPUT13 (Safety Switch)
72 Checks the signal input INPUT14 (Edge Sensor)
73 Checks the signal input INPUT15 (Thread trimming not allowed)
74 Checks the signal input INPUT20 (First step for pedal going forward)
75 Checks the signal input INPUT21
(First step for pedal going backwards)
76 Checks the signal input INPUT22 (Second step for pedal going backwards)
77 Checks the solenoid movement voltage 0~64
78 Checks external volume value 0~64
79 Checks the pedal analog output 0~64
80 Checks the synchronizer signal
81 Checks the signal from encoder A/B
82 Checks the signal from encoder R/S/T
83~ NOT USED
89 NOT USED
Along with the input, it will say "on" or off"
Increases by each rotation
of the sewing machine
1) increases when sewing machine
rotates clockwise
2) decreases when sewing machine
rotates in counterclockwise
1) When sewing machine is rotating
clockwise
101
100 110 010
011 001 101
2) When sewing machine is rotating
counterclockwise
101 001 011 010
110 100 101
