57
No. Function StepRange
Initial value
[ Caution ]
If the specific items of the parameter are changed carelessly, they could break down or damage the machine, so the user must be
well-trained before using it.
90 Sewing machine pulley size ? 0 9999 1pulse
91 Distance between up-stop ~ low-stop
(the standard is the pulley's normal direction rotation) ? 0
9999 1pulse
92 Programming the upper stop location
(the standard is the pulley's normal direction rotation) ? 0
359 1degree
- Not valid for model S-III
93 Programming the low-stop location
(the standard is the pulley's normal direction rotation) ? 0
359 1degree
- Not valid for model S-III
94 Index pulse occurring position ? 0
359 1degree
(the standard is the pulley's normal direction rotation)
- Turn the pulley manually and stop it in the position you want.
95 CAM type thread release solenoid operation position ? 0
359 1degree
- Turn the pulley manually and stop it in the position you want.
96 CAM type thread release solenoid release position ? 0
359 1degree
- Turn the pulley manually and stop it in the position you want.
97 CAM type thread trimming solenoid operation position ? 0
359 1degree
- Turn the pulley manually and stop it in the position you want.
98 CAM type thread trimming solenoid release position ? 0
359 1degree
- Turn the pulley manually and stop it in the position the user wants
99 Manual and automatic set up of solenoid operation / 1 0/1 0=manual set up
release position in CAM type thread trimming 1=automatic set up
