SunSynk SUNSYNK-8K-SG01LP1 User Manual

SINGLE PHASE HI 8kW | User Manual11
3. TECHNICAL SPECIFICATIONS
Model SUNSYNK-8K-SG01LP1 / SUNSYNK-8K-SG03LP1
Product Type Hybrid Inverter
Enclosure IP65
Ambient Temperature -45ºC ~ 60ºC (>45ºC derating)
Protection Level Class I
Charge Mode
Battery Voltage 48Vd.c (40Vd.c ~ 60Vd.c)
Battery Current 190Ad.c (max.)
AC Input Voltage
120/240Va.c (split phase), 208Va.c (2/3 phase), 220/230Va.c
(single phase)
AC Input Frequency 50/60Hz
AC Input Rated Current 36.4/34.8Aa.c
Max. AC Input Current 40/38.3Aa.c (max.)
Max. AC Input Power 8800W
Max. Apparent Output Power 8800VA
PV Input Voltage 370Vd.c (125Vd.c ~ 500Vd.c)
MPPT Input Voltage 150Vd.c ~ 425Vd.c
PV Input Current 26Ad.c + 26Ad.c
Max. PV Input Power 10400W
Max. PV Isc 44Ad.c + 44Ad.c
Utility-Interactive
AC Output Voltage
120/240Va.c (split phase), 208Va.c (2/3 phase), 220/230Va.c
(single phase)
AC Output Frequency 50/60Hz
AC Output Rated Current 36.4/34.8Aa.c
Max. AC Output Current 40/38.3Aa.c (max.)
Max. AC Output Power 8800W
AC Output Rated Power 8800VA
AC Output Power Factor 0.95 leading to 0.95 lagging
Max. AC Isc 145Aa.c
Battery Discharge Voltage 40Vd.c ~ 60Vd.c
Battery Discharge Current 190Ad.c (max.)
Battery Discharge Power 8000W
Stand Alone
AC Output Voltage
120/240Va.c (split phase), 208Va.c (2/3 phase), 220/230Va.c
(single phase)
AC Output Frequency 50/60Hz
AC Output Rated Current 36.4/34.8Aa.c
AC Output Rated Power 8800W
Max. Continuous AC Passthrough Cur-
rent
50Aa.c
Peak Output Power 16000W (10 seconds)
Battery Discharge Voltage 40Vd.c ~ 60Vd.c
Max. Discharge Current 190A (max.)
Compliance
VDE-AR-N 4105:1028-11; DINVDE V 0124-100:2020-06; IEC/
EN62109-1/2:2010; IEC/EN62109-1/2:2011
