SINGLE PHASE HI 8kW| User Manual76
6.3. Mode III: With Aux-Load
Grid
Backup Load
On-Grid Home Load
Battery
Solar
CT
AC cable DC cable
Smart Load
6.4. Mode IV: AC Couple
On-Gen+AC couple
AC cable DC cable
CT
Battery
Solar
Grid
Backup Load
On-Grid Home Load
On-Grid Inverter
