SINGLE PHASE HI 8kW| User Manual75
6. OPERATION MODES
6.1. Mode I: Basic
Grid
Backup Load On-Grid Home Load
CT
Battery
Solar
AC cable DC cable
COM cable
6.2. Mode II: Generator
Grid
Backup Load On-Grid Home Load
Battery
Solar
CT
AC cable DC cable
Generator
