SUNSYNK MAX | Installer Manual54
Grid Mode: General Standard - for example, EN50549_CZ_PPDS_L16A, NRS097, G98/G99. Please follow
your local grid code and choose the corresponding grid standard from the drop-down menu. If you can-
not nd your local grid standard from this menu, please manually input the grid settings as per instruc-
tions below.
G100 - Please ensure the inverter is set to G99/G100 for compliance to G100 regulations.
Set the Grid frequency.
Set the Grid type.
Unlock Grid Settings: The inverters grid settings are automatically locked, so if you need to make
changes to the grid settings you will need to select this, and it will as for password code.
Grid Supply Page
In the Settings menu, click on the GRID icon.
What this page displays:
Example:
During 01:00-05:00, when the battery SOC is lower than 80%, it will use the grid to charge the battery until
the battery SOC reaches 80%.
During 05:00-08:00 and 08:00-10:00, when battery SOC is higher than 40%, the hybrid inverter will discharge
the battery until the SOC reaches 40%.
During 10:00-15:00, when the battery SOC is higher than 80%, the hybrid inverter will discharge the battery
until the SOC reaches 80%.
During 15:00-18:00, when the battery SOC is higher than 40%, the hybrid inverter will discharge the battery
until the SOC reaches 40%.
During 18:00-01:00, when the battery SOC is higher than 35%, the hybrid inverter will discharge the battery
until the SOC reaches 35%.
16000
16000
16000
16000
16000
16000
