Super Products Camel 1200 (Ejector Unloading) - Page 47

SAFETY
Publication: 0028607 1-37
1
Figure 1-34: Right Side of Truck
ITEM DESCRIPTION TYPE PART NO. SEE FIG.
1 Valve positions NOTICE 0026476 1-53
2 Do not go under raised body WARNING 0007448 1-52
3 Closed INSTRUCTION 3050-00338 1-54
4 Open INSTRUCTION 3050-00337 1-55
5 Body drain INSTRUCTION 3050-00578 1-56
6 Rotating shafts can be dangerous WARNING 3050-01179 1-57
7 Water tank fill INSTRUCTION 3050-00579 1-58
8 Level gauge INSTRUCTION 0007543 1-59
9 Hydraulic reservoir INSTRUCTION 3050-0051 1-60
10 Suction line valve CAUTION 3050-01286 1-61
11 1.2.3. INSTRUCTION 0007522 1-62
12 Remote grease INSTRUCTION 0007541 1-63
13 Disengage all drives WARNING 0007428 1-44
14 Rotating shafts can be dangerous WARNING 3050-01180 1-46
15 Handgun connection INSTRUCTION 3050-00009 1-64
16 High-pressure water WARNING 0007433 1-65
