Super Products Camel 1200 (Ejector Unloading) - Page 51

SAFETY
Publication: 0028607 1-41
1
Figure 1-38: Right Side of Reel
ITEM DESCRIPTION TYPE PART NO. SEE FIG.
1 Vacuuming unstable materials DANGER 0026568 1-81
2 Handgun connection INSTRUCTION 3050-00009 1-64
3 Transportation latch INSTRUCTION 3050-00136 1-82
4 High-vacuum port WARNING 3050-00116 1-83
5 High-pressure hose area WARNING 0007437 1-84
6 Winter recirculation INSTRUCTION 3050-00205 1-85
7 Drain here INSTRUCTION 3050-00024 1-50
8 Reel locking pin INSTRUCTION 3050-00641 1-86
9 Stand clear CAUTION 3000-01123 1-75
1
6
9
5
4
7
3
2
8
