Chapter 4: AMI BIOS
4-47
4-10 Management
Set all options for Management in this section.
ACPI Settings
ACPI Sleep State
This feature selects the ACPI Sleep State tha
t the system will enter into
when the suspend button is activ
ated. The options are Suspe
nd Disabled,
and
S3 (Suspend to RAM)
.
122
