Supero C7Z170-SQ User Manual

Chapter 4: AMI BIOS
4-21
VRM Total Current Limit Capability
Use this feature to set the CPU integrated voltage regulator when under
extreme high load for VRM total current limit. The options are 100%,
110%, 120%, 130%, 140%, 150%, 160%, 170%, 180% and 190%.
VRM Per-Phase Current Limit Capability
Use this feature to set the CPU integrated voltage regulator when un-
der extreme high load for VRM per-phase current limit. The options are
100%, 110%, 120%, 130%, 140%, 150%, 160%, 170% and 180%.
PMON Slope
This option sets the PMON Slope value in 1/100 increments. For a 1.25
slope, enter 125. Press "+" or "-" on your keyboard to change the value.
PMON Offset
Use this feature to set the PMON offset value. Range is -255. Enter '0'
for auto. Press "+" or "-" on your keyboard to make a selection. The
default setting is "+".
PSYS PMax Current
This option sets the PSYS PMax Current in 1/8A increments. Range is
from 0~8192. For a PMAX of 125A, enter 1000. Enter '0' for auto. Press
"+" or "-" on your keyboard to change the value.
System Agent VR Settings
This option sets the System Agent VR Settings. Press "+" or "-" on your
keyboard to change the value.
Core/IA VR Settings
This option sets the Core IA VR Settings. Press "+" or "-" on your key-
board to change the value.
Ring VR Settings
This option sets the Ring VR Settings. Press "+" or "-" on your keyboard
to change the value.
