Supermicro C7Z170-SQ Motherboard User’s Manual
1-3 Motherboard Features
CPU
Single Intel Core i3/i5/i7 6th generation processor
in an LGA1151 type socket.
Memory
Four (4) slots support up to 64GB of unbuffered,
non-ECC, 3000+MHz(OC) DDR4 memory*
Dual-channel memory
DIMM sizes
UDIMM 4GB, 8GB, 16GB
Chipset
Intel® Z170 Express
Expansion Slots
Two (2) PCH PCI-E 3.0 X1 (in X4) slot
One (1) CPU PCI-E 3.0 X4 (in X16) slot
One (1) PCH PCI-E 3.0 X4 slot
One (1) CPU PCI-E 3.0 X16 slot
One (1) CPU PCI-E 3.0 X8 (in X16) slot
One (1) M.2 slot
Network
Connections
One (1) Gigabit Ethernet Controller
One (1) RJ-45 rear I/O panel connectors with Link
and Activity LEDs
I/O Devices SATA Connections
SATA 3.0 (6Gb/s) Six (6) I-SATA 0~5, via Intel Z170
RAID 0, 1, 5, 10
USB Devices
Two (2) USB 2.0, Two (2) USB 3.0, one (1) USB
3.1 'type C' ports on the rear I/O panel
Four (4) Front-Accessible USB 2.0 ports on two
headers and Four (4) Front Accessible USB 3.0 ports
on two headers.
Keyboard/Mouse
One shared PS/2 Keyboard/Mouse port on the I/O
backpanel
Other I/O Ports
One (1) DisplayPort, One (1) DVI-D Port, One (1)
HDMI Port
One (1) Serial Port header (COM1)

Supero C7Z170-SQ Specifications

General

Brand	Supero
Model	C7Z170-SQ
Category	Motherboard
Language	English
