Supero C7Z170-SQ User Manual

Chapter 1: Introduction
1-3
Audio
One (1) High Denition Audio 7.1 channel connector
supported by Realtek ALC1150 on the back panel
One (1) Front Panel Audio Header
One (1) S/PDIF Out on the rear side of the chassis
Super I/O
Nuvoton NCT6792D-B
BIOS
128 Mb AMI BIOS
®
SPI Flash BIOS
Plug and Play (PnP0, DMI 2.8, PCI 2.3, ACPI
1.0/2.0/3.0, and USB Keyboard
Power Configuration
ACPI/ASPM Power Management
Main Switch Override Mechanism
Internal/External Modem Ring-On
Power-on mode for AC power recovery
Health Monitoring CPU Monitoring
Onboard monitors: CPU core, +3.3V, +5V, +/- 12V, +3.3V
Stby, +5V Stby, VBAT, HT, Memory PCH Temperature,
System Temperature, and CPU Temperature
CPU 6+1 phase switching voltage regulator
CPU/System overheat LED and control
CPU Thermal Trip support
Thermal Monitor support
Fan Control
Fan status monitoring with rmware 4-pin fan
speed control
Low noise fan speed control
System Management
PECI (Platform Environment Conguration Inter-
face) 2.0 support
System resource alert via SuperDoctor
®
III
SuperDoctor III, NMI
Chassis Intrusion header and detection
CD Utilities
BIOS ash upgrade utility
Drivers and software for Intel® Z170 Express
chipset utilities
Other
ROHS 6/6 (Full Compliance, Lead Free)
Dimensions
ATX form factor (12.0" x 9.6") (304.8 mm x
243.84 mm)
