4-13
Chapter 4: AwardBIOS
RxD, TxD Active
This option allows the user to set the "RxD, TxD Active" functions. The settings
are "Hi, Hi", "Hi, Lo", "Lo, Hi", and "Lo, Lo."
IR Transmission Delay
If "Enabled", the transmssion of IR (Infrared) signals will be delayed. The
settings are "Enabled" and "Disabled."
UR2 Duplex Mode
This allows you to set the mode for the UR2 Duplex Mode. The settings are
"Full" and "Half."
Use IR Pins
This item sets the mode for Use IR Pins. The settings are "RxD2", "TxD2" and
"IR-Rx2Tx2."
Onboard Parallel Port
This option allows the user to set the address and the corresponding IRQ for
the onboard Parallel port. The settings are "Disabled" , "378/IRQ7", "278/IRQ5"
and "3BC/IRQ7."
Parallel Port Mode
This option set the mode for the onboard Parallel port. The settings are "SPP",
"EPP", "ECP" and "ECP+EPP."
EPP Mode Select
This option allows the user to select the EPP mode. The settings are "EPP 1.9"
and "EPP 1.7."
EPP Mode Use DMA
This option allows you to select which DMA is assigned to EPP. The settings
are "1" and "3".
