4-17
Chapter 4: AwardBIOS
PCI Slot 2 IRQ Select
Use this setting to assign the IRQ# for PCI slot 2. The settings are "Auto", "3",
"4", "5", "7", "9", "10" and "11."
PCI Slot 3/PCI64 Slot 1, 2
Use this setting to assign the IRQ# for PCI slot 3 and the two 64-bit PCI slots.
The settings are "Auto" ,"3", "4", "5", "7", "9", "10" and "11."
PCI Slot 4 IRQ Select
Use this setting to assign the IRQ# for PCI slot 4. The settings are "Auto","3",
"4", "5', "7", "9", "10". and "11."
Reset Configuration Data
If you have installed a new add-on device and this add-on device has caused
conflicts in system configuration and has resulted in system boot-up failure,
then, select "Enabled" to reset "Extended System Configuration Data" (ESCD)
for the OS to reboot the system. The settings are "Enabled" and "Disabled."
Resources Controlled By
The Award BIOS can automatically configure all the boot devices and all Plug
and Play compatible devices. However, if this item is set to "Auto (ESCD)", the
user is not able to set the IRQ DMA and memory address, since the Award
BIOS will automatically assign the values to these fields. The settings are
"AUTO (ESCD)" and "Manual."
PCI/VGA Palette Snoop
To obtain ooptimum system performance, this item has been pre-set to
"Disabled" by the manufacturer. The settings are "Enabled" and "Disabled."
