Chapter 1: Introduction
1-3
Audio
One (1) High Denition Audio 7.1 channel connector
supported by Realtek ALC888S on the back panel
One (1) Front Panel Audio Header
Super I/O
Nuvoton NCT6776D
BIOS
128 Mb AMI BIOS
®
SPI Flash BIOS
Plug and Play (PnP0, DMI 2.8, PCI 2.3, ACPI
1.0/2.0/3.0, and USB Keyboard
Power
Configuration
ACPI/ASPM Power Management
Main Switch Override Mechanism
Internal/External Modem Ring-On
Power-on mode for AC power recovery
Health
Monitoring
CPU Monitoring
Onboard monitors: +3.3V, +5V, +12V, +3.3V Stby, +5V
Stdby, VBAT, Memory, PCH Temp, System Temp, Memory
Temp (ECC UDIMM only)
CPU 3+2 phase switching voltage regulator
CPU Thermal Trip support
Thermal Monitor support
Fan Control
Fan status monitoring with rmware 4-pin fan speed
control
Low noise fan speed control
System
Management
PECI (Platform Environment Conguration Interface)
2.0 support
System resource alert via SuperDoctor
®
III
SuperDoctor III, NMI
Chassis Intrusion header and detection
CD Utilities
BIOS ash upgrade utility
Drivers and software for Intel® C236 Express chipset
utilities
Other
ROHS 6/6 (Full Compliant, Lead Free)
Dimensions
ATX form factor (12.0" x 9.6") (304.8 mm x 243.84
mm)
