1-2
Supermicro X11SAE/X11SAE-F Motherboard User’s Manual
1-3 Motherboard Features
CPU
Support for a single E3-1200 v5 series, a 6th Genera-
tion Intel® Core™ i7/i5/i3 series, a Pentium or Celeron
processor, in an LGA 1151 (H4) socket.
Memory
Four (4) slots support up to 64GB of unbuffered, ECC/
non-ECC, 2133MHz DDR4 memory
Dual-channel memory
DIMM sizes
UDIMM 4GB, 8GB, 16GB
Chipset
Intel® C236 Express
Expansion Slots
Two (2) CPU PCI-E 3.0 X16 slots (X16/NA or X8/X8)
Three (3) PCH PCI-E 3.0 X1 (open edge) slots on
the X11SAE and Two on the X11SAE-F.
Two (2) PCI 33MHz slots
One (1) M.2 slot (32Mb/s)
Network
Connections
Two (2) Gigabit Ethernet Controllers, with LAN2 shared
with IPMI on the X11SAE-F
Two (2) RJ-45 rear I/O panel connectors with Link
and Activity LEDs
I/O Devices SATA Connections
SATA 3.0 (6Gb/s) Eight (8) I-SATA 0~7, via Intel C236
RAID 0, 1, 5, 10
USB Devices
Two (2) USB 2.0, Two (2) USB 3.0, Two (2) 10Gb/s
USB 3.1 'type A' ports on the rear I/O panel
Six (6) Front-Accessible USB 2.0 ports on three head-
ers on the X11SAE, Four (4) Front-Accessible USB 2.0
ports on two headers on the X11SAE-F, and Four (4)
Front Accessible USB 3.0 ports on two headers, on
both models.
Other I/O Ports
One (1) DisplayPort 1.2, One (1) DVI-D Port, One (1)
HDMI 1.4 Port, One (1) VGA Port (X11SAE-F only),
IPMI Port (shared with LAN2 on the X11SAE-F only)
SATA DOM Power Connector
Two (2) Serial Port headers (COM1 & COM2)
