Manufacturing Mode (JPME2)
Close pins 2 and 3 of Jumper JPME2
to bypass SPI ash security and force
the system to operate in Manufactur-
ing Mode, allowing the user to ash the
system rmware from a host server for
system setting modications. See the
table on the right for jumper settings.
Manufacture Mode (JPME2)
Jumper Settings
Jumper Setting Denition
Pins 1-2 Normal (Default)
Pins 2-3 Manufacture Mode
A. VGA Enable
B. Manufacturing Mode
Onboard VGA Enable/Disable
(JPG1)
Close pins 1 and 2 of jumper JPG1 to en-
able to the onboard graphics controller,
close pin #2 and pin #3 to disable. See
the table on the right for jumper set-
tings. Supported on the X11SAE-F only.
VGA Enable/Disable (JPG1)
Jumper Settings
Jumper Setting Denition
Pins 1-2 Enabled (Default)
Pins 2-3 Disabled
