Supermicro X11SAE/X11SAE-F Motherboard User’s Manual
Connector Description
AUDIO FP Front Panel Audio Header
B3 Onboard Battery
BIOS RESTORE BIOS Restore Button
COM1/COM2 Serial COM Headers
DVI/VGA Digital Visual Interface/VGA Ports
FAN1 - FAN5 System/CPU Fan Headers (FAN1: CPU Fan)
HD AUDIO High-Denition Audio Connector
HDMI/DP High-Denition Multimedia Interface/DisplayPort Ports
J23 M.2 PCI-E 3.0 X4 Slot
JD1 Speaker/Buzzer (Pins 1-4: Speaker, Pins 3-4: Buzzer)
JF1 Front Panel Connector
JL1 Chassis Intrusion Header
JLED1 3-Pin Power LED
JPI2C1 Power I2C System Management Bus (Power SMB) Header (X11SAE-F only)
JPW1 24-pin ATX Power Connector
JPW2 8-pin 12V DC Power Connector
JSD1 SATA DOM Power
JSTBY1 Standby Power Header
JTBT1 General Purpose I/O Header for a Thunderbolt add-on card
JTPM1 Trusted Platform Module/Port 80 Connector
LAN1/LAN2 Gb LAN (RJ45) Ports
I-SATA0 - I-SATA7 Intel® SATA Ports
SLOT1/SLOT2 PCI 33MHz Slots
SLOT3/SLOT5/SLOT7 PCH PCI-E 3.0 X1 Slots
SLOT4 CPU PCI-E 3.0 X8 (IN X16) Slot
SLOT6 CPU PCI-E 3.0 X16 Slot
SP1 Internal Speaker/Buzzer
I-SGPIO1 - I-SGPIO2 Serial General Purpose I/O Headers
UID Unit Identication Switch
USB 0/1, 8/9, 14/15
Back panel USB Ports (Ports 0/1: USB 2.0, Ports 8/9: USB 3.0, Ports 14/15: USB
3.1)
USB 2/3, 4/5, 6/7
USB 10/11, 12/13
Front Access USB Headers (Headers 2/3, 4/5, 6/7: USB 2.0, Headers 10/11 and
12/13: USB 3.0)
