X9DRW-3LN4F+/3TF+ Jumpers
Jumper
Description Default Setting
JBT1
Clear CMOS See Chapter 3
JI
2
C1/JI
2
C2 SMB to PCI-E Slots Pins 2-3 (Normal)
JPB1 BMC Enable Pins 1-2 (Enabled)
JPG1 VGA Enable Pins 1-2 (Enabled)
JPL1 LAN1/LAN2 Enable Pins 1-2 (Enabled)
JPL2 LAN3/LAN4 Enable Pins 1-2 (Enabled)
JWD1 Watch Dog Pins 1-2 (Reset)
X9DRW-3LN4F+/3TF+ Connectors
Connectors Description
COM1/COM2 Backplane COM Port1/Front Accessible COM2 Header
FAN1~5, FANA1 CPU/System Fan Headers
I-SATA 0~5 Intel SB SATA Connectors 0~5
JF1 Front Panel Control Header
JF2 LAN 3/4 Link/Activity LED Indicators
JIPMB1 4-pin External BMC I
2
C Header (for an IPMI Card)
JL1 Chassis Intrusion
JOH1 Overheat/Fan Fail LED
JPI
2
C1 Power Supply SMBbus I
2
C Header
JPW1 ATX 24-Pin Power Connector (See Warning on Pg. 1-6.)
JPW2/JPW3 12V 8-Pin Power Connectors (See Warning on Pg. 1-6.)
JPW4 12V 4-Pin Power Connector (See Warning on Pg. 1-6.)
JSD1 SATA DOM (Device_On_Module) Power Connector
JSTBY1 Standby Power Header
JTPM1 TPM (Trusted Platform Module)/Port 80
KB/Mouse Keyboard/Mouse
LAN1/2 G-bit Ethernet Ports 1/2
LAN3/4 1G-bit or 10G-bit Ethernet Ports 3/4 (GLAN Ports for
-3LN4F+, 10GLAN Ports for -3TF)
(IPMI) LAN IPMI_Dedicated LAN
SAS 0~3, 4~7 Serial_Attached_SCSI Connectors 0~3, 4~7
SP1 Onboard Buzzer (Internal Speaker)
SXB1A/1B/1C/1D SMC-Proprietary WIO_L (Left) Add-On Card Slot
SXB2 SMC-Proprietary WIO_R (Right) Add-On Card Slot
T-SGPIO 1/2 Serial-Link General_Purpose IO Headers (J17/J18)
