Sutron Corporation Satlink Operations & Maintenance Manual, Rev 8.04.2 11/3/2016 pg. 12
 Expanded SDI-12 capacity with 2 independent SDI-12 inputs
 Optional cell/Iridium modems for redundant 2-way communications
 Expanded log from 120,000 to 1,000,000 readings, expandable to 1,000,000,000
readings (32 GB) via internal SDHC card
 Improved GUI program that runs on Android, iPhone, PC or MAC devices
3.1. SL3- 1
The figure below shows the connections provided by the SL3-1. A description of each of the connections
is provided in the following paragraphs.
Power/Battery
Status LED
USB to PC
GOES
Antenna
Connector
RS232 to PC
Wi-Fi/ failsafe
reset button
5 separate
terminal blocks
5 separate terminal
blocks
Earth Ground
GPS Antenna
Connector
2 Expansion Slots
USB Host
