Suzuki GF60A - Battery Requirement Description; Component Location; Charging System Components Location; Diagnostic Information and Procedures

Charging System: 1K-2
Battery Requirement Description
ZAJ6111B01002
Refer to “Battery Requirement” in Section 0A (Page 0A-5).
Component Location
Charging System Components Location
ZAJ6111B03001
Refer to “Wiring Harness Routing Diagram” in Section 4A (Page 4A-4).
Diagnostic Information and Procedures
Charging System Diagnosis
ZAJ6111B04001
Condition Possible cause Correction / Reference Item
Alternator (Battery charge
coil) does not charge.
Open or short circuit lead wires. Repair or replace.
Open or short circuit battery charge coil. Replace.
Rectifier/Regulator failure. Replace.
Main fuse blown out. Replace.
Poor or broken battery connection. Repair or Replace.
Alternator (Battery charge
coil) overcharge.
Rectifier/Regulator failure. Replace.
Poorly grounded rectifier/regulator. Repair or Retighten.
Unstable charging Short circuit battery charge coil. Replace.
Loose lead wire connection. Repair or replace.
Rectifier/regulator failure. Replace.
Poor or broken battery connection. Repair or replace.
