Suzuki GF60A - Page 252

2A-14 Housing and Bracket:
9) Remove the driveshaft housing with oil pan.
10) Remove the lower mount assembly.
Account for lower mount bolt (10), washer (11), side
lower mount (12), lower mount (13), forward damper
(14), cushion (15), side lower mount (16) and washer
(17).
11) Remove the three bolts and upper mount cover (18).
12) Remove the upper mounts (19), upper thrust mount
(20), upper mount bolts (21) and washers (22).
13) Remove the bolt and water indicator union (23) and
water hose (24) (if necessary).
14) Remove the seven bolts (25) and engine holder (26).
IAJ611210039-01
IAJ611210040-01
11
10
12
13
14
15
16
17
IAJ611210041-01
18
IAJ611210042-01
20
22
22
21
21
19
19
IAJ611210043-01
24
23
IAJ611210044-01
26
25
25
IAJ611210045-01
25
IAJ611210046-01
