0B-4 Maintenance and Tune-Up:
5) Install new gasket and oil drain plug.
Tighten engine oil drain plug to specified torque.
To avoid water entry into oil pan or oil
leakage into the environment do not reuse
gasket once removed. Always use a new
gasket.
Tightening torque
Engine oil drain plug (a): 13 N·m (1.3 kgf-m, 9.5
lbf-ft)
6) Pour the recommended engine oil into oil filler
opening, then install oil filler cap.
Recommended Engine Oil
• 4 stroke motor oil
• NMMA FC-W classification:
SG, SH, SJ, SL, SM. or API classification:
SG, SH, SJ, SL, SM.
• Viscosity rating:
NMMA FC-W 10W-40 or SAE 10W-40
Engine oil amounts
Oil change only: 2.7 L (2.9/2.4 US/Imp.qt)
Oil filter change: 2.9 L (3.0/2.6 US/Imp.qt)
7) To reset oil change reminder system’s operation time
to zero (cancellation).
NOTE
Refer to “Oil Change Reminder System
Description” in Section 1A (Page 1A-14).
a) Turn ignition key to “ON” position.
b) Pull out emergency stop switch plate (4).
c) Pull up emergency stop switch knob (5) three
times in ten seconds. A short beep will be heard
if cancellation is successfully finished.
d) Turn ignition key to “OFF” position, then set
emergency stop switch plate (4) in original
position.
8) Start engine and allow it to run for several minutes at
idle speed.
Check oil drain plug for oil leakage.
Turn off engine and wait for approx. two minutes,
then recheck engine oil level.
(a)
5
4
