3A-1 Drive Shaft / Axle: Front
Driveline / Axle
Drive Shaft / Axle
Front
General Description
Front Drive Shaft Construction
S3RH0A3111001
A ball fixed type constant velocity joint is used on the wheel side of front drive shaft. For A/T vehicle, a tripod type
constant velocity joint is used on the differential side and transfer side. For M/T vehicle, a double offset type constant
velocity joint (DOJ) is used on the differential or center shaft side. The drive shaft can slide through the tripod joint or
the double offset joint in the extension / contraction direction.
Diagnostic Information and Procedures
Front Drive Shaft Symptom Diagnosis
S3RH0A3114001
Condition Possible cause Correction / Reference Item
Abnormal noise Wear or breakage of drive shaft joint Replace.
Wear or breakage of center bearing Replace.
