Suzuki Liana RH413 Service Manual

Automatic Transmission/Transaxle: 5A-81
Selector Lever Components
S3RH0A5106004
Selector Lever Inspection
S3RH0A5106005
Check select lever for smooth and clear-cut movement and position indicator for correct indication.
For operation of select lever, refer to the figure.
3 N·m (0.3 kg-m)
3.5 N·m (0.35 kg-m)
2.5 N·m (0.25 kg-m)
1
2
3
4
5
I3RH0A510034-01
1. Selector lever assembly 3. Indicator assembly 5. Illumination lamp
2. Knob assembly 4. Shift lock solenoid (if equipped)
I3RH0A510022-01
