Power Assisted Steering System: 6C-22
Tightening Torque Specifications
S3RH0A6307002
NOTE
The specified tightening torque is also described in the following.
“P/S Gear Box Components”
“P/S Pump Components”
Reference:
For the tightening torque of fastener not specified in this section, refer to “Fasteners Information in Section 0A”.
P/S belt tension
For vehicle with A/C system
7 – 9 mm (0.28 – 0.35 in.) deflection for new belt
9 – 11 mm (0.35 – 0.43 in.) deflection for used belt
(The push force should be about 100 N (10 kg, 22lb).)
For vehicle without A/C system
4 – 9 mm (0.16 – 0.35 in.) deflection for new and used belts
(The push force should be about 100 N (10 kg, 22 lb).)
Item Specification
Fastening part
Tightening torque
Note
N⋅mkgf-mlb-ft
Tension pulley bolt and nut 25 2.5 18.0 )
Tie-rod end castle nut 45 4.5 32.5 ) / )
Wheel nut 85 8.5 61.5 )
Tie-rod end lock nut 45 4.5 32.5 )
Gear box mounting bolt 55 5.5 40.0 )
Gear box cylinder pipe flare nut 25 2.5 18.0 )
Gear box high and low pressure pipe flare nut 35 3.5 25.0 )
Steering shaft upper and lower joint bolt 25 2.5 18.0 )
Tie-rod ball nut 70 7.0 50.5 )
Pump cover bolt 28 2.8 20.0 )
Pressure switch 28 2.8 20.0 )
Plug 60 6.0 43.5 )
Suction connector bolt 12 1.2 8.5 )
