Alarm no.
Alarm text
Function
Priority Stop Indication
LED
Delay Resetting
0=blocked 0=In operat. 0=Off s=seconds M=manual
A=A alarm 1=Stop 1=On m=minutes A=automatic
B=B alarm
89
NO COMM. SA PREFILTER PRESS. SENSOR
The air handling unit’s control unit cannot establish
correct communication with supply air prefilter pres-
sure sensor.
B*** 0 1 10 s A
90
NO COMM. EA PREFILTER PRESS. SENSOR
The air handling unit’s control unit cannot establish
correct communication with extract air prefilter pres-
sure sensor.
B*** 0 1 10 s A
91
FROST PROTECTION, PREHEATING, BELOW ALARM LIMIT
The sensor for the frost protection monitor, preheat-
ing, has measured a temperature lower than the
preset temperature. Factory setting: 7 °C.
A 1 1 3 s M
92
FROST PROTECTION PREHEATING SENSOR DEFECTIVE
The sensor for the frosting protection monitor, pre-
heating, is lacking, is not connected or is faulty, if an
air heater for hot water is connected.
A 1 1 3 s A
93
PREHEATING SENSOR DEFECTIVE
The sensor for preheating is lacking, is not connected
or is faulty, if an air heater for hot water is con-
nected.
A 1 1 3 s A
94
EL. AIR HEATER, PREHEATING, TRIPPED
The thermal overload protection for the connected
electric air preheater, has tripped or is not connected.
A*** 1 1 3 s M
95
PREHEATING BELOW SETPOINT
The preheating temperature is below the preset set-
point (for ERS and Supply air control) or Min SA temp
(for Extract air control) longer than 0 minutes.
A*** 1 1 20 m M
96
SPARE
97
NO COMMUNICATION ReCO PRESSURE SENSOR
The air handling unit’s control unit cannot establish
correct communication with the flow pressure sensor
for ReCO.
A*** 1 1 10 s A
98
ReCO DAMPER MOTOR FAULTY
The damper motor does not actuate damper to
the right position. The position-confirming output
signal from the damper is not equivalent to the input
control signal.
A*** 1 1 10 m M
99
TIME LOCK TRIPPED
Contact Swegon or their representative.
– – – –**** M
100-
101
SPARE
102
COOLING VALVE I/O-7 DEFECTIVE
Controls of the Cooling valve do not obtain the same
signal on AI 1 as on AU1 on I/O-module.
B*** 1 0 10 m M
103
HEATING VALVE I/O-7 DEFECTIVE
Controls of the Heating valve do not obtain the
same signal on AI 2 as on AU2 on I/O-module
A*** 1 0 10 m M
104
COOL. CIRCUIT PUMP I/O-7 TRIPPED.
Controls of the cooling circuit pump do not obtain
correct signal according to set function.
B*** 1 0 30 s M
*** Blocked if the hand terminal does not display the main menu.
**** Adjustable: 0-99 months.
