Function Factory preset value Adjusted value
Service period
Alarm limit (Mon) 12
Alarm priority See also pages that follow –
Alarm output A
X NO NC NO NC
B
X NO NC NO NC
Hand-held terminal settings
Language English
Flow unit
l/s X m
3
/s m
3
/h l/s m
3
/s m
3
/h
Min/max adjustment
8)
Setpoint SA/EA (°C)
8)
15.0/40.0
Min. limit SA (°C)
8)
13.0/18.0
Max. limit EA (°C)
8)
25.0/45.0
Breakpoint- ERS regulation (°C)
8) 15.0/23.0
Differential SA/EA (°C)
8)
1.0/5.0
Base settings –
Communication
EIA-232
Protocol GSM modem
Address 1
Speed 9600
Parity None
Stop bit 1
EIA-485
Protocol Modbus RTU
Address 1
PLA (Exoline) 1
ELA (Exoline) 1
Speed 9600
Parity None
Stop bit 1
Ethernet
Mac Id Individual
DHCP server Inactive
IP-adress 10.200.1.1
Port No. 80
Netmask 255.0.0.0
GateWay 000.000.000.000
DNS Server
No. 1 000.000.000.000
No. 2 000.000.000.000
Modbus TCP
IP 000.000.000.000
Port No. 502
Netmask 000.000.000.000
BACNet IP
Function Inactive
Device ID 0000000
Port nr. 47808
The values refer to the sizes in due succession: 04, 05, 08, 12, 14, 20, 25, 30, 35, 40, 50, 60, 70 and 80.
1) 0.15, 0.20, 0.30, 0.40, 0.40, 0.55, 0.75, 0.85, 0.90, 1.1, 1.5, 1.7, 2.0, 2.2
2) 0.25, 0.30, 0.40, 0.60, 0.60, 1.0, 1.3, 1.65, 1.85, 2.2, 2.8, 3.4, 3.5, 4.6
3) 0.35, 0.50, 0.60, 0.90, 0.90, 1.4, 1.8, 2.5, 2.6, 3.3, 3.5, 4.3, 5.0, 5.8
4) Only in combination with Heating BOOST, Cooling BOOST and Flow BOOST.
5) Only in combination with Demand control. 0.08, 0.08, 0.10, 0.20, 0.20, 0.20, 0.30, 0.30, 0.60, 0.60, 0.80, 0.80, 1.0, 1.0
6) 0.10, 0.10, 0.20, 0.30, 0.30, 0.40, 0.50, 0.60, 0.80, 0.90, 1.2, 1.5, 1.8, 2.0
7) Only in combination with Flow BOOST.
8) Not applicable if only GOLD SD extract air handling units are installed
9) Not applicable if only GOLD SD supply air or extract air handling units are installed
