Alarm No.:
Function
Factory preset values Adjusted value
Priority Indication Effect Priority Indication Effect
0=blocked LED 0=Operat. 0=blocked LED 0=Operat.
A=A alarm 0=Off 1=Stop A=A alarm 0=Off 1=Stop
B=B alarm 1=On B=B alarm 1=On
43 Ext. alarm No.2 tripped B *** 1 0
44 SA duct pressure below setpoint B *** 1 0
45 EA duct pressure below setpoint B *** 1 0
46 SA duct pressure above setpoint B *** 1 0
47 EA duct pressure above setpoint B *** 1 0
48 Supply airflow below setpoint B *** 1 0
49 Extract airflow below setpoint B *** 1 0
50 Supply airflow above setpoint B *** 1 0
51 Extract airflow above setpoint B *** 1 0
52 Supply air filter dirty B *** 1 0
53 Extract air filter dirty B *** 1 0
54 Service period past alarm limit B *** 1 0
55 No comm. SA air flow pressure sensor A *** 1 1
56 No comm. EA air flow pressure sensor A *** 1 1
57 No comm. SA filter pressure sensor B *** 1 0
58 No comm. EA filter pressure sensor B *** 1 0
59 No comm. SA duct pressure sensor A *** 1 1
60 No comm. EA duct pressure sensor A *** 1 1
61 No comm. r.hx. pressure sensor B *** 1 0
62 No communication to I/O-module No:0 B *** 1 0
63 No communication to I/O-module No:1 B *** 1 0
64 No communication to I/O-module No:2 B *** 1 0
65 No communication to I/O-module No:3 B *** 1 0
66 No communication to I/O-module No:4 B *** 1 0
67 No communication to I/O-module No:5 B *** 1 0
68 No communication to I/O-module No:6 B *** 1 0
69 No communication to I/O-module No:7 B *** 1 0
70 No communication to I/O-module No:8 B *** 1 0
71 No communication to I/O-module No:9 B *** 1 0
72 No communication to main controller I/O A 1 1
73 Plate heat exch., damper motor faulty A *** 1 1
74 Coil heat exch. pump tripped A *** 1 1
75 Supply air humidity sensor faulty A *** 1 1
76 Extract air humidity sensor faulty A *** 1 1
78 Humidity sensor for heat exch. faulty B *** 1 0
79 Coil heat exch. valve faulty A *** 1 1
80 Temperature monitor below alarm limit A *** 1 1
81 Supply air-d temperature sensor faulty B *** 1 0
82 Extract air-d temperature sensor faulty B *** 1 0
85 CoolDX, C1 tripped A 1 0
