Alarm No.:
Function
Factory preset values Adjusted value
Priority Indication Effect Priority Indication Effect
0=blocked LED 0=Operat. 0=blocked LED 0=Operat.
A=A alarm 0=Off 1=Stop A=A alarm 0=Off 1=Stop
B=B alarm 1=On B=B alarm 1=On
152 Supply air sensor in extra zone faulty A 1 1
153 Extract air sensor in extra zone faulty A 1 1
154 Electric air heater for extra zone, tripped A 1 1
155 EA temp. in extra zone below alarm limit A*** 1 1
156 Supply air in extra zone below alarm limit A*** 1 1
159 No communication with COOL DXS module A 1 0
160 COOL DXS, low pressure, below alarm limit A 1 0
161 COOL DXS, high pressure, above alarm limit A 1 0
162 COOL DXS low pressure sensor defective A 1 0
163 COOL DXS high pressure sensor defective A 1 0
164 COOL DXS K1 has tripped A 1 0
165 COOL DXS K2 has tripped A 1 0
166 COOL DXS K3 has tripped A 1 0
167 COOL DXS K1 too many restarts A 1 0
168 COOL DXS K2 too many restarts A 1 0
169 COOL DXS K3 too many restarts A 1 0
170 COOL DXS fan has tripped A 1 0
171 COOL DXS incorrect phase sequence A 1 0
* Not adjustable, always stops the air handling unit
** Not adjustable, stops the air handling unit at temperature below +5 °C
*** Blocked if the hand terminal does not display the main menu.
**** Cannot be blocked.
