EN-16
FUEL RESERVE WARNING LIGHT“ ”
when the ignition key is turned, the light comes on for a few seconds and
then goes off. If the light comes on while riding the motorcycle, it means that
the fuel has gone into reserve (3 litres) and you need to refuel as soon as
possible.
ABS SYSTEM FAULT WARNING LIGHT “ ”
When the key is turned, the ABS control unit runs a self-test , the light comes
on for a few seconds and then goes off indicating there is no fault.
If instead the light comes on while the motorbike is running, it means that
there is a fault of the ABS braking system:
-Stop and turn off the engine.
-wait for a few minutes and restart the engine.
If the light turns on again, see the closest SWM dealer to check the ABS system.
MULTIFUNCTION DISPLAY
1) Speedometer
Indicates motorcycle speed.
2) Speed scale indication:
Km/h = kilometres/hour
Mph = miles/hour
3) Display parameters
The following parameters that will be displayed in the field (4) can be individ-
ually set in this field.
ODO = Odometer (read-only value)
TRIP = Partial odometer (see /TRIP settings)
5) Unit of measurement
Mile = indicates that the value shown in the ODO and TRIP functions is in miles
Km = indicates that the value shown in the ODO and TRIP functions is in kilo-
metres
6) Engine cooling water temperature indicator.
